Welcome back for another installment of the systemd series. Throughout this

series, we discuss ways to use systemd to understand and manage your system.

This article focuses on how to convert legacy scripts you may have customized on

your system.

SysV init scripts

The init system used previously in Linux was called SysVinit. Before we start, it’s

helpful to know that systemd has a lot of compatibility features for SysVinit. In

some cases, you may not have to edit �les to maintain your custom solutions. But

in others, it’s helpful to know how to adapt to and use new systemd technology.

A script used to manage a service in SysVinit was known as a SysV init script. With

some additions, it was known as a LSB, or Linux Standards Base, init script. Fear

not, backwards compatibility for legacy scripts remains 99.9% intact with systemd.

That means you don’t need to rush to convert all your scripts simply to adopt a

systemd-based OS like Fedora. However, there are a number of advantages to

doing so.

systemd: Converting sysvinit scripts

systemd: Converting sysvinit scripts - Fedora M...

https://fedoramagazine.org/systemd-converting-...

1 of 8

28-12-15 10:35

Init scripts are actually imperative shell scripts executed by an interpreter. Here,

“imperative” means they contain the commands the system runs to manage the

service. However, systemd unit �les are declarative statements of intent. They give

hints to systemd to manage a service, but systemd takes care of execution. As a

result, unit �les are typically much shorter than the SysV init scripts that they

replace. That’s because they don’t have to worry about implementation, just the

intent of the service.

The �rst step in migrating a SysV init script is to examine the script that you wish

to convert. Let’s use the sshd init script from Fedora 16 as an example. The

previous link will show you the script before it was converted to a systemd unit �le.

Here’s a fun fact: everything handled by that 184 line shell script is now handled by

27 lines of systemd con�guration, spread across two unit �les.

Runlevels vs. targets

Reviewing the init script linked above, let’s look more closely at a few important

parts. First is this line:

# chkconfig: 2345 55 25

The �rst set of numbers, 2345, indicates in which runlevels in the SysV world this

script should run. A SysV runlevel is a de�nition of a system state where certain

processes and services should run. There are a speci�c set of runlevels de�ned:

0: halt

1: single-user

2: multi-user

3: multi-user with networking

4: unde�ned (user de�ned)

5: multi-user with display manager (graphical login)

6: reboot

In systemd, there is no concept of runlevels. These are replaced by targets. In

systemd, there can be an unlimited set of targets, each represented by a unit �le

with a .target suf�x. The analogous target to SysV runlevel 3 in systemd is called

multi-user.target. Similarly, a unit corresponding to runlevel 5 is called

graphical.target.

Targets can and do depend on each other. So only once the system has reached

multi-user.target does it start the services speci�ed in graphical.target. There are

systemd: Converting sysvinit scripts - Fedora M...

https://fedoramagazine.org/systemd-converting-...

2 of 8

28-12-15 10:35

also implicit dependencies on basic.target which, as the name suggests,

establishes basic system services and functions. Some of these happen through

their own target dependencies, like network.target.

Service ordering

The next two numbers in the SysV init script, 55 and 25, determine the order for

starting and stopping the service. Under SysVinit, scripts run strictly in order. The

order is determined by naming a set of links in folders. If a new script is placed in

the wrong order to start or stop, the service may fail, the system may appear to

hang, or other errors may result.

On the other hand, directives in systemd unit �les like Requires= and After= ensure

that units run in the correct order. They don’t require prior knowledge about other

units or services on the system. For instance, if your unit runs a service that

requires the network, you can add Requires=network.target

and After=network.target to the unit �le. It will only be run once the network is

activated.

There are also dependencies included in the old SysV init script. However, they’re

not enforced if you simply run the script outside the control of the init system. One

of the major features of systemd is deterministic results from running an action.

That’s a lot of code

Following header information, such as hard and soft dependencies (Required-Start,

Required-Stop, Should-Start, and Should-Stop) is the description of the service.

In this case that’s Start up the OpenSSH server daemon. Following are various

functions that implement what the script does. The standards refer to certain

verbs the script must implement, such as start, stop, and restart.

As mentioned earlier, though, the systemd way of doing things is declarative.

Rather than having to de�ne and code a set of functions, you specify the process

to execute. There’s no need, for example, for a large amount of code for a common

task such as retrieving the process ID (PID) the service starts.

Let’s look at the start() function of this script to see what it does, and let’s examine

it line by line. This is a shell script, a program of instructions to be run by the shell

started by the init system. Don’t worry if you don’t know the language; the

instructions are explained below.

systemd: Converting sysvinit scripts - Fedora M...

https://fedoramagazine.org/systemd-converting-...

3 of 8

28-12-15 10:35

start()

{

[ -x $SSHD ] || exit 5

[ -f /etc/ssh/sshd_config ] || exit 6

# Create keys if necessary

/usr/sbin/sshd-keygen

echo -n $"Starting $prog: "

$SSHD $OPTIONS && success || failure

RETVAL=$?

[ $RETVAL -eq 0 ] && touch $lockfile

[ $RETVAL -eq 0 ] && cp -f $XPID_FILE $PID_FILE

echo

return $RETVAL

}

In order, here’s what the init system does:

Checks if the sshd binary exists and is executable, and if not, exits with a status

code of 5.

Checks whether the con�guration �le /etc/ssh/sshd_con�g exists, and if not,

exits with status code 6

Runs the sshd-keygen binary to make keys, if they don’t already exist

Sends a message to the screen/log that it’s about to start the service

Runs the service, and outputs a success or failure message for startup of the

sshd process

Captures a return value for the sshd process itself; 0 means sshd has

successfully become a service daemon

Based on the return value, marks several marker �les to indicate the service is

running, in case the system administrator tries to run it again

Sends out a “next line” message for the screen/log

Passes the return value out in case it’s needed elsewhere

Note this is only one function in the SysV sshd init script. Many other functions

also need to be coded, including stop, restart, and others. Those are over a

hundred more lines of code! But what does the systemd unit �le look like in

comparison?

systemd: cuts down on code

In contrast, here’s the sshd.service unit �le from a Fedora 23 installation. Notice

how much smaller and easier to read this �le is:

[Unit]

Description=OpenSSH server daemon

Documentation=man:sshd(8) man:sshd_config(5)

systemd: Converting sysvinit scripts - Fedora M...

https://fedoramagazine.org/systemd-converting-...

4 of 8

28-12-15 10:35

After=network.target sshd-keygen.service

Wants=sshd-keygen.service

[Service]

EnvironmentFile=/etc/sysconfig/sshd

ExecStart=/usr/sbin/sshd -D $OPTIONS

ExecReload=/bin/kill -HUP $MAINPID

KillMode=process

Restart=on-failure

RestartSec=42s

[Install]

WantedBy=multi-user.target

The �rst few lines again describe the systemd unit, and where you can read more

about it. Here are what the remainder of the lines mean, with links to systemd

documentation:

After declares ordering, and describes that network.target

and sshd-keygen.service should run �rst.

Wants describes that sshd-keygen should be run in order for this service to

start. Note the subtle difference from ordering. systemd considers order and

dependencies orthogonal, meaning just because sshd-keygen comes �rst

doesn’t mean it is a dependency of sshd — although in this case it is.

Wants means systemd should run sshd-keygen.service, but if that doesn’t

complete successfully (for instance, if SSH server keys already exist), sshd will

still run. If sshd-keygen.service needed to complete successfully, you’d

use Requires instead.

EnvironmentFile, similar to SysVinit, is a con�guration �le with options for sshd.

It contains a set of key=value pairs that will be passed to sshd.

ExecStart is the command that runs to start sshd. This replaces the entire start

function in the old initscript. The $OPTIONS variable here is what is speci�ed in

EnvironmentFile for the variable OPTIONS.

ExecReload is the command that runs if the sysadmin reloads the

sshd daemon. This replaces the entire reload function in the old initscript.

KillMode sets how systemd will stop the service. In this case, systemd will stop

the main sshd process only. Any additional sshd child processes will continue

to manage their open SSH sessions. This is not an option used often, but it is

important here. For instance, it stops you from killing your own SSH session

when you run systemctl!

Restart determines how systemd manages the service if it stops unexpectedly.

In this case, on-failure means virtually any unexpected failure will cause

systemd to restart sshd. If sshd stops normally, though, such as with

a systemctl stop command, it will not be restarted.

RestartSec allows 42 seconds of sleep time before sshd is restarted due to an

systemd: Converting sysvinit scripts - Fedora M...

https://fedoramagazine.org/systemd-converting-...

5 of 8

28-12-15 10:35

unexpected stop.

WantedBy means when the command systemctl enable sshd.service is run, a

link is placed in the multi-user.target.wants directory by default. This is one of

the mechanisms systemd uses to determine units to run for speci�c targets.

So multi-user.target and any target that depends on it, will include

running sshd.service.

There are of course many other directives available, and the systemd docs cover

all of them. But if you were to write your own unit �le for a simple service, you

needn’t use even all the options shown here. You might only need a few directives

like After, ExecStart, and WantedBy. If you look in /usr/lib/systemd/system/ on your

own Fedora system, you can �nd many other .service unit �les that you can follow

as a template.

Additional hints

Another notable feature of systemd, though, is that it doesn’t abandon

compatibility for SysVinit. Some administrators have created their own custom

startup scripts such as /etc/rc.d/rc.local. If you’re not prepared to convert it, don’t

worry — systemd will honor it, using the rc-local.service �le already included.

Remember, if you are building custom system services for your Fedora, it’s best to

place them into /etc/systemd/system. Typically /etc/ is where all

system con�guration or customization is kept. This allows you to avoid putting

customizations in /usr/lib/systemd/system which is managed by Fedora’s package

system.

If you’d like to read another example and explanation of converting, check out this

blog entry from the “systemd for administrators” series.
